Our SafeTCap® TAC-231R Center Frame Section was designed to cap over and repair the center frame on the 2005-2015 Toyota Tacoma Regular (Standard) Cab both 2wd and 4wd models. This part is 18.5″ long and 5.75″ tall, and caps over the outer side of the frame beginning about 11″ behind the transmission cross member and 18.5″ towards the rear. This part is designed to coincide with the TAC-230 and the TAC-232X with our jigsaw style weld edges for a seamless fit, and should be welded onto the existing frame along all overlapped edges.
The TAC-231R is manufactured from only high quality, domestically sourced 11ga cold rolled steel. SafeTCap® never uses any imported steel from overseas.
